Length
From 4.87m (16') to 10.36m (34')
Internal Height
2.13m (7')
External Width
2.55m (8'4")
Standard Features
- All alloy rear loading gates using horizontal design for safety
- Alloy slurry tank
- All steel components hot-dip galvanised or zinc plated
- Alloy deck poles for ease of handling and reduced weight
- Alloy folding decks to suit length of pen for quick loading
- Anti-slip alloy floor
- Brakes: Commercial cam brakes operated by hydraulics
- Capacity: 14 tonnes/16 tonnes/18 tonnes
- Conspicuity tape (mandatory to all vehicles and trailers registered after 10th July 2011)
- Draw Beam: Adjustable sprung draw bar (increased ride stability)
- Easy clean design
- Finish: Shot blasted and painted all over using two pack Nexa paint
- Fixed floors welded all round
- Hand Brake: Mechanical
- High-grade alloy monocoque construction
- Houghton ‘H’ frame cattle gates with integrated alloy sheep gates
- Hydraulic run-up to 2nd deck stores in roof for loading of adult cattle to bottom deck
- LED marker lights to comply with legal requirements
- Lights: Marker lights to comply with legal requirements
- Matt black rear ramp to prevent startling through sun glare
- Nexa Autocolor Turbo Plus 2-pack paint system in one colour of your choice
- One gate per deck supplied to suit each 3.66m length of transporter
- One light per pen externally switched
- Open ventilation to all decks with closing flaps to 1st deck only
- Spring-assisted alloy-planked rear door with smooth exterior
- Stainless steel hinge pins
- Strobe light to rear
- Suspension: Commercial Multi leaf springs
- Towing Eye: Ø50 Heavy duty eye
- Unique internal width of 2.53m enables larger animals to stand crossways
